Buzzer CPT13B03 Przetwornik piezoelektryczny

Specification

Rated Voltage 3 Vp-p, square wave

Operating Voltage 1 - 20 Vp-p, square wave

Operating Frequency 4000+/-500Hz

Typical Sound Output 75dB min. at 3Vp-p 10cm 4KHz 25 oC

Typical Operating Current 1mA at 3Vp-p

Capacitance 10,000+/-30% pF at 100Hz 1Vrms

Operating Temperature -40 oC to +85 oC

Storage Temperature -40 oC to +90 oC

Termination Description 2 soldering pins, Sn plated Brass

Construction Materials Case Plastic, Noryl PX9406
